P40 Series Multi-way Valve Multiple Monoblock Manual Directional Control Valve

Name: P40 Series Multiway Valve Multiple Monoblock Manual Directional Control Valve
Brand: Seric
Price: 1 USD

Brand Name : Seric

Model Number : P40 Series

Certification : CE, ISO

Place of Origin : Guangzhou

MOQ : 1 Piece

Price : Negotiable

Payment Terms : T/T,L/C,Western Union

Supply Ability : 5000

Delivery Time : 1-15 days

Packaging Details : Carton Box/Wooden Case

After Warranty Service : Online Support

OEM : Accept

Condition : 100% Brand-new

Quality : High-Quality

Application : Industrial Machinery

Selling Units : Single item

Contact Now

P40 Series Multi-way Valve Multiple Monoblock Manual Directional Control Valve

Features

l Integrated Check Valve: Prevents hydraulic oil backflow

l Integrated Relief Valve: Adjusts hydraulic system working pressure

l Oil Circuit: Parallel design, with power beyond option

l Control Modes: Manual, pneumatic, hydraulic-electric (selectable)

l Valve Structure: Monoblock type

l Spool Functions: O, Y, P, Q types available

l Optional Add-ons: Hydraulic lock can be fitted to ports A and B

l Extended Control Options: Manual, pneumatic, electro-pneumatic, hydraulic-electric, etc.

Specifications

Parameter	Metric Value	Imperial Value
Nominal flow rate	40 L/min	10.6 US GPM
Operating pressure (max)	250 bar	3626 psi
Operating range	15 ~ 75 mm²/s	15 ~ 75 cst
Minimum viscosity	12 mm²/s	12 cst
Maximum viscosity	400 mm²/s	400 cst
Ambient temperature range	-40° ~ 80°C	-40° ~ 176°F
Structure	Monoblock: 1 - 7 sections	-

P40 Series Multi-way Valve Multiple Monoblock Manual Directional Control Valve

Product Tags:

P40 Series multi-way valve

manual directional control valve with warranty

monoblock directional control valve

Wholesale P40 Series Multi-way Valve Multiple Monoblock Manual Directional Control Valve from china suppliers

P40 Series Multi-way Valve Multiple Monoblock Manual Directional Control Valve Images
